PACKAGING
OF COVERED WINDING WIRES
|
| CYLINDRICAL
PLASTIC REELS ACC. TO IEC 60264-2, DIN 46399 |
Id
|
Ref.No.
|
Flange ø
|
Barrel ø
|
Traverse
|
Overall
Width
|
Bore
|
Weight
Capacity
|
1
|
S-22
|
250
(9.84)
|
160
(6.30)
|
160
(6.30)
|
200
(7.87)
|
22
(0.87)
36 ( 1.42)
102 (4.00)
|
22
(48.50)
|
2
|
S-48
|
355
(13.98)
|
224
(8.82)
|
160
(6.30)
|
200
(7.87)
|
36
(1.42)
51 (2.00)
|
48
(105.80)
|
| CONICAL
REELS ACC. TO IEC 60263-3, DIN 46383 |
Id
|
Ref.No.
|
Flange ø
|
Barrel ø
|
Traverse
|
Overall
Width
|
Bore
|
Weight
Capacity
|
1
|
PT-1
|
93.5/103(3.68/4.06)
|
54/60(2.13/2.36)
|
98(3.85)
|
119(4.68)
|
16(0.63)
|
1(2.20)
|
2
|
PT-2
|
105/115(4.13/4.53)
|
60/67(2.36/2.64)
|
150(5.90)
|
169(6.65)
|
16(0.63)
|
2(4.40)
|
3
|
PT-4
|
122/140(4.80/5.51)
|
74/85(2.91/3.35)
|
172(6.77)
|
200(7.87)
|
26(1.02)
|
4(8.80)
|
4
|
PT-6
|
147/160(5.78/6.30)
|
90/100(3.54/3.94)
|
150(5.90)
|
180(7.08)
|
20(0.78)
|
6(13.20)
|
5
|
PT-10
|
157/180(6.18/7.08)
|
95/180(3.74/4.25)
|
202(7.95)
|
226(8.90)
|
30(1.18)
|
10(22.0)
|
6
|
PT-15
|
180/200(7.08/7.87)
|
95/110(3.74/4.33)
|
201(7.91)
|
225(8.85)
|
30(1.18)
|
15(33.0)
|
7
|
PT-20
|
212/230(8.34/9.06)
|
132/150(5.20/5.91)
|
247(9.84)
|
277(10.90)
|
32(1.25)
|
20(44.0)
|
8
|
PT-25
|
215/230(8.34/9.06)
|
110/130(4.33/5.12)
|
250(9.84)
|
275(10.82)
|
30(1.18)
|
25(55.0)
|
9
|
PT-45
|
236/250(9.29/9.84)
|
140/160(5.51/6.30)
|
335(13.18)
|
400(15.75)
|
100(3.93)
|
45(99.0)
|
10
|
PT-90
(Under Development)
|
300/315(11.81/12.40)
|
180/200(7.09/7.87)
|
425(16.73)
|
500(19.69)
|
100(3.93)
|
90(198.0)
|
11
|
PT
-225
(Under
Development)
|
375/400(14.76/15.75)
|
205/230(8.07/9.06)
|
605(23.82)
|
665(26.18)
|
100(3.93)
|
225(496.0)
|
| CYLINDRICAL
WOODEN REELS ACC. IS : 2069-1981 |
Ref.No.
|
Flange
Dia
|
Traverse
|
Barrel
Dia
|
Fiange
Thiskness
|
Overall
With Max
|
Bore
Dia
|
Capacity
Max
|
Nominal
|
Min
|
Max
|
(1)
|
(2)
|
(3)
|
(4)
|
(5)
|
(6)
|
(7)
|
(8)
|
(9)
|
(10)
|
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
kg
|
4
520
|
450 ± 5
|
200 ± 0/-3
|
300 ± 5
|
38 ± 5
|
282
|
35.5
|
35.5
|
38.0
|
70
|
5
624
|
560 ± 5
|
240 ± 0/-3
|
300 ± 5
|
38 ± 5
|
322
|
35.5
|
35.5
|
38.0
|
150
|
Note: The
first two digits and the last two in each reference number
indicate the flange diameter and the traverse respectively
in centimeter. |
|
|
